Aeration Chamber (Room)
Aeration room or aeration chamber is for degassing of products after EO sterilization.
After EO sterilization, the products can be degassed in the aeration chamber (room) in accordance with ISO11135. It effectively accelerates the removal of residual gas emissions from the sterilized product, ensuring it can achieve the acceptable criteria. It saves energy consumption and improves the sterilizer's working efficiency. A separate automatic control system controls the aeration chamber (room).
Features of Our Aeration System
- An aeration system is optional equipment for the sterilization process.
- Our professional engineers will advise you on the necessity and design of the aeration chamber (room).
- Aeration chamber (room) accelerates the removal of residual EO from the product, making it ready more quickly for dispatch and use.
- The equipment is precisely controlled according to preset parameters, fully automated, easy to operate, and energy-saving.
Primary Technical Parameters of Aeration
Inner chamber volume: 3/6/10/15/20/25/30...300m³, customize acceptable.
Chamber material: Stainless steel or color steel plate or earth built house
Degassing temperature: 0-60℃
Degassing time: 1~200 hrs
Heated air circulation times: >30times/hr
Air change times (outer circulation): >60times/hr
